Home » Products » Multiparameter Meter » HI2002

HI2002

HI2002
HI2002
Product Code : HI2002
Brand Name : HANNA EQUIPMENTS
Product Description

Hanna Instruments is proud to introduce the world’s most innovative pH/ORP meter: edge®.

edge’s groundbreaking design is the culmination of Hanna’s vision, design capabilities, integrated production and world class R&D. edge is a single, easy to use meter that can measure pH and ORP.

Advanced pH Electrode Diagnostics

edge features advanced pH electrode diagnostics to ensure worry-free measurements. Diagnostics include Hanna’s exclusive CAL CheckTM feature that alerts users to potential problems during calibration. The Sensor CheckTM feature for glass and junction integrity is enabled when using optional pH electrodes with a matching pin.

Capacitive Touch

edge features a capacitive touch keypad that gives a distinctive, modern look. The keypad has a fast response and is sensitive enough to be used with laboratory gloves. Since the keypad is part of the screen, there are no buttons to get clogged with sample residue.

pH Specifications

pH Range-2.000 to 16.000 pH (Standard Mode), -2.00 to 16.00 pH (Basic Mode)
pH Resolution0.001 pH, 0.01 pH
pH Accuracy (@25ºC/77ºF)±0.01 pH, ±0.002 pH
pH Calibration5 points (Standard mode)
 1.68, 4.01 (3.00†), 6.86, 7.01, 9.18, 10.01, 12.45, and two custom buffers;  3 points (Basic mode) 4.01; 6.86; 7.01; 9.18; 10.01
pH Temperature CompensationATC: -5.0 to 100.0ºC; 23.0 to 212.0°F*
mV Range±1000.0 mV; ±2000.0 mV
mV Resolution0.1 mV
mV Accuracy±0.2 mV (±999.9 mV); ±1 mV (±2000 mV)
Relative mV CalibrationSingle point calibration

Temperature Specifications

Temperature Range-20.0 to 120.0 ºC, -4.0 to 248.0 °F
Temperature Resolution0.1 °C, 0.1 °F
Temperature Accuracy±0.5 °C, ±0.9 °F
°C/°FYes

Additional Specifications

pH Electrode DiagnosticsGlass and reference junction diagnostics ( HI 11311 & HI 12301 only), out of calibration range , probe condition, response time
GLPYes
Loggingup to 1000*** records organized in: Manual log-on-demand (Max. 200 logs), Manual log-on-stability (Max. 200 logs), Interval logging *** (Max. 600 samples; 100 lots)
Connectivity1 micro USB port for charging and PC connectivity, 1 USB port for storage
Environment0 to 50°C (32 to 122°F), RH max 95% non-condensing
Battery Type/LifeBuilt-in rechargeable battery with up to 8 hours of continuous use
Power Supply5 VDC adapter (included)
Dimensions202 x 140 x 12.7mm (8” x 5.5” x 0.5”)
Weight250 g (8.82 oz)
Ordering Informationedge® HI2002 includes benchtop docking station with electrode holder, wall mount cradle, USB cable, HI11310 glass body refillable pH electrode with temperature sensor, 2 sachets each of pH 4, 7, 10, cleaning solution, 5 VDC power adapter and instruction manual.
Notes

* temperature limits will be reduced to actual probe/sensor limits
*** For standard mode only (logging)
† pH 3.00 is only visible when using specific pH electrodes and will replace pH 4.01 buffer
